Tactile & Optical Testing of Electronic Devices
High Repeatability – Force Control – Various Angles
Electronic devices are becoming smaller, more complex, operate in different environments, and include several types of components that require tactile, optical, and electronic testing methods. The position of these devices in the final assembly demands precise positioning of the inspection tool in several degrees of freedom. PI offers powerful flexible motion systems for various test methods that can be integrated into customer production lines while maintaining capacity and throughput.
Key Features of PI's Motion Systems
Unique range of motion technologies to design most advanced solutions
Industrial high-performance motion control platform provides coordinated motion of all axes for maximum throughput
Easy connection and management of third-party sensors and test devices with flexible EtherCAT® connectivity
Can be integrated as a subsystem under most PLCs and automation controllers
Workpiece Positioning
- Magnetic direct drive linear motors for high precision and high velocity
- Absolute encoder with 1nm resolution
- XY drag chain cable management
>> V-551 Precision Linear Motor Stage
Positioning of Testing Device
- Ball screw linear motor or voice coil stage
- Cable management integration
- Holding brake or counterbalance
- Direct-measuring linear encoder
>> M-511 High-Precision Linear Stage
Sensor Positioning at Various Angles
- Parallel-kinematic hexapod
- Six degrees of freedom
- Freely definable center of rotation
>> H-811 6-Axis Miniature Hexapod
Force Control of Measuring Sensor
- PIMag® voice coil linear actuator
- Force sensor with 1 mN resolution
- Weight force compensation
>> V-275 PIMag® Voice Coil Linear Actuator
Automation Control
ACS SPiiPlus EtherCAT-based motion control platform operates as an independent machine controller or as a subsystem under most PLCs and automation controllers
- Motion Controller
>> ACS SPiiPlusES - Universal Servo Drives
>> ACS NPMpm
